Product Summary
The 74HCT132 is quad 2-input nand schmitt trigger. The 74HCT132 is high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL (LSTTL). The 74HCT132 is specified in compliance with JEDEC standard no. 7A. The 74HCT132 contains four 2-input NAND gates which accept standard input signals. The 74HCT132 is capable of transforming slowly changing input signals into sharply defined, jitter-free output signals.
Parametrics
74HCT132 absolute maximum ratings: (1)propagation delay nA, nB to nY CL = 15 pF; VCC = 5 V: 11ns HC 17 ns HCT; (2)input capacitance: 3.5pf HC 3.5 pFHCT; (3)power dissipation capacitance per gate : 24pf HC 20 pF HCT.
Features
74HCT132 features: (1)Output capability: standard; (2)ICC category: SSI.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 74HCT132D,653 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND SCHMITT TRIG |
Data Sheet |
|
|
||||||||||||
|
74HCT132DB,112 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND |
Data Sheet |
|
|
||||||||||||
|
74HCT132DB,118 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND |
Data Sheet |
|
|
||||||||||||
 |
74HCT132N,652 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-IN NAND GATE SCHMITT TRIGGER |
Data Sheet |
|
|
||||||||||||
|
74HCT132PW,112 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND |
Data Sheet |
|
|
||||||||||||
|
74HCT132PW,118 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT NAND SCHMITT TRIG |
Data Sheet |
|
|
||||||||||||
|
74HCT132D,652 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2IN NAND SCHMIT |
Data Sheet |
|
|
||||||||||||
 |
74HCT132 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
