MC14050BDR2G

Noninverting Hex Buffer, 3.0 V to 18 V, 16SOIC, 740mW, ±10 mA, MC14050BDR2G

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.12~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.12~0.20

PartNumber:: MC14050BDR2G

Brand:: ON Semiconductor - ON | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. helen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-02-16

From Other Seller

Part Number:MC14050BDR2G
US $0.12 - 0.20
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MC14050BDR2G is an Noninverting Hex Buffer. It is constructed with MOS P-Channel and N-Channel enhancement mode devices in a single monolithic structure. The device finds primary use where low power dissipation and/or high noise immunity is desired. The MC14050BDR2G provides logic level conversion using only one supply voltage, VDD. The input-signal high level (VIH) can exceed the VDD supply voltage for logic level conversions. Two TTL/DTL loads can be driven when the MC14050BDR2G is used as a CMOS-to-TTL/DTL converter(VDD = 5.0 V, VOL≤ 0.4 V, IOL ≥ 3.2 mA).

Parametrics

MC14050BDR2G absolute maximum ratings: (1)VDD DC Supply Voltage Range: -0.5 to +18.0 V; (2)Vin Input Voltage Range (DC or Transient): -0.5 to +18.0 V; (3)Vout Output Voltage Range (DC or Transient): -0.5 to VDD + 0.5 V; (4)Iin Input Current (DC or Transient) per Pin: ±10 mA; (5)Iout Output Current (DC or Transient) per Pin: ±45 mA; (6)PD Power Dissipation, per Package(Plastic): 825mW; (SOIC): 740mW; (7)TA Ambient Temperature Range: -55 to +125 ℃; (8)Tstg Storage Temperature Range: -65 to +150 ℃; (9)TL Lead Temperature (8.Second Soldering): 260 ℃.

Features

MC14050BDR2G features: (1)High Source and Sink Currents; (2)High-to-Low Level Converter; (3)Supply Voltage Range = 3.0 V to 18 V; (4)VIN can exceed VDD; (5)Meets JEDEC B Specifications; (6)Improved ESD Protection On All Inputs; (7)Pb-Free Packages are Available.
