Product Summary
The ZEN132V230A16LS is a polymer enhanced precision Zener diode micro-assemblie that helps protect sensitive electronics from damage caused by inductive voltage spikes, voltage transients, use of incorrect power supplies and reverse bias. In the event of sustained high power conditions, the PPTC element of the ZEN132V230A16LS “trips” to limit current and generate voltage drop. This functionality of the ZEN132V230A16LS helps protect both the Zener and the follow-on electronics, effectively increasing the diodes power handling capacity.
Parametrics
ZEN132V230A16LS absolute maximum ratings: (1)VZ(V): 13.60; (2)IZt(A): 0.1; (3)IHOLD @ 20°C(A): 2.3; (4)RTyp (Ω): 0.04; (5)R1MAX (Ω): 0.06; (6)VINT MAX (V): 16V; (7)Test Current (A): 5A; (8)IFLT MAX Voltage (A): +2/-40; (9)Test Voltage (V): +20/-12V.
Features
ZEN132V230A16LS features: (1)RoHS compliant; (2)Overvoltage transient suppression; (3)Hold currents up to 2.3A; (4)Time delayed, overvoltage trip; (5)Time delayed, reverse bias trip; (6)Power handling on the order of 30 watts; (7)Integrated device construction.
